Pumps
High pressure syringe pump (Bench Top, Single Pump series) |
|
|
The versatile BTSP series are designed for applications requiring accurate pulseless flow and pressure control of both inorganic (brine, solvent…) and organic fluids (hydrocarbons, microbial solution…). These pumps deliver specified pressure, flow rate and volume at both ambient and reservoir conditions, and can operate at either constant pressure or constant flow rate. |
OPTIONS:
Conversion of wetted parts into hastelloy
This option is required when corrosive fluids such as high concentration brine or acidic solutions are to be handled. The hastelloy wetted parts encompass the pump cylinder, tubing, connectors and valves.
Temperature control jacket
The jacket wraps around the pump cylinder, enabling an isothermal flow of liquid through the 1/4” upper and lower hose connectors, keeping the temperature of the pumped fluid constant.
Heating system
To reproduce reservoir temperatures, the heating system is utilized to heat and maintain a homogeneous, isothermal (up to 150°C) temperature profile in the pump cylinder. The pump panel is used to enter, display and regulate the temperature (reading: 0.1°C). An embedded temperature probe continuously measures the cylinder’s temperature.
BENEFITS:
* Compact
* Extreme long life
* Wide range of flow rate at maximum pressure
* Touch screen panel
